📌 Product Overview
The SG-6505 / SG-6506 is a high-end industrial Direct-to-Film (DTF) printer designed for large-scale production environments.
With 5 or 6 printheads available, this series delivers extremely fast output, stable print quality, and continuous 24/7 production capability.
It supports PET DTF film, allowing full-color, high-saturation transfer printing that can be applied to cotton, polyester, blends, denim, leather, canvas, nylon, and more — without needing pre-treatment.
🖨 Printer Specifications
Specification SG-6505 / SG-6506
Model SG-6505 (5 heads) / SG-6506 (6 heads)
Print Heads 5-head / 6-head configuration
Ink Type DTF Pigment Ink
Power Supply 220V / 110V
Working Temperature / Humidity 20–30°C / 45–65%
RIP Software Support Maintop, PhotoPrint, CADlink
Print Interface USB 3.0
Print Media PET Transfer Film
Print Width 600mm
⚡ Printing Speed Performance
Mode Output Speed
3-Pass Mode ~40 m²/hour
6-Pass Mode ~30 m²/hour
(Speed may vary depending on artwork coverage and environment conditions.)
📦 Machine Size & Weight
Unit Dimension Weight
Printer Size 1900 × 900 × 1670 mm 210 kg
Packing Size (Shipping) 1930 × 930 × 1560 mm 270 kg
⚙️ Optional Automatic Powder Shaker Units
Model Size (mm) Weight
Model A Powder Shaker 2700 × 960 × 1170 mm 230 kg
Model A Packing 2480 × 1000 × 1280 mm 300 kg
Model B Powder Shaker 2700 × 1050 × 1100 mm 240 kg
Model B Packing 2620 × 1100 × 1230 mm 280 kg
